GE IS220PPRFH1A process output/gateway module

1. Core Identity

IS220PPRFH1A offers 8 individually isolated SPDT relays plus a Modbus-TCP/RTU gateway, letting Mark VIe drive field devices or older DCS segments without extra interface boxes.

2. Key Specifications

| Relays | 8 × SPDT, 5 A @ 250 VAC / 30 VDC, resistive |
| Contact life | 100 k ops at rated load; hot-swap replacement in <30 s |
| Coil control | Driven through FET switches, status read-back for STCO diagnostics |
| Serial port | RS-485 (2-wire) software-selectable Modbus-RTU master/slave, 1.2–115.2 kbps |
| Ethernet | 10/100 Base-TX with RJ-45; supports Modbus-TCP, 16 concurrent sockets |
| Isolation | 2 kV relay-to-logic, 1 kV channel-to-channel |

3. Mapping & Configuration

Relay coils and register map imported automatically into Mark VIe I/O configurator; no secondary ladder required.

4. Mechanical & Power

Single-slot slice, 38 mm – shares rack power (4.2 W max)

–40 … +70 °C, 5–95 % RH non-condensing

5. Certifications

UL 508, CE, IEC 61131-2, RoHS, ABS marine option.
