1. UR8FH in one sentence
UR8FH is a 4-channel CT/VT synchronous-measurement card for GE Multilin UR relays. One slot delivers 64 samples/cycle, ±0.1° phase accuracy and streams data over IEC 61850-9-2LE or Modbus-TCP—protection, metering and power-quality in one go.
2. Plug-and-play compatibility at a glance
|
UR family
|
Free slots for UR8FH
|
On-board protocol
|
Typical application
|
|
F650
|
1–3
|
Modbus-TCP
|
Feeder protection + PQ
|
|
T60
|
2–4
|
IEC 61850
|
Transformer differential
|
|
B90
|
1–8 (redundant)
|
PRP/HSR ring
|
Bus-bar impedance
|
3. Core specifications
· 4 independently configurable CT/VT inputs, 50/60 Hz auto-detect
· 0.2 S class metering, 0.5 % FS accuracy from –40 °C to +85 °C
· 2.5 kV channel-to-channel isolation; 4 kV surge withstand
· Burden: <0.15 VA (CT) | <0.05 VA (VT) – keeps site error budget low
· Built-in delta-wye math & magnitude/phase up to the 63rd harmonic
· Firmware upgrade via UR front port; no recalibration required
4. Head-to-head: UR8FH vs. UR8CH
|
Key point
|
UR8FH
|
UR8CH
|
|
Channel count
|
4 CT/VT
|
8 CT/VT
|
|
Phase accuracy
|
±0.1°
|
±0.2°
|
|
Harmonics
|
63rd
|
15th
|
|
Slot consumption
|
1
|
1
|
|
Sweet-spot use
|
High-precision PQ / synchro-check
|
Cost-effective over-current
|
5. Field success snapshots
· 500 kV smart substation, Shanxi: replaced legacy PMU cards, cut annual outage by 120 h
· Offshore platform, South China Sea: 3×UR8FH inside T60 for 4-wdg transformer, saved one 19" rack
· EV charger plant: harmonic trending to IEC 61000-3-6, pass-rate rose from 92 % to 99 %
6. One-line ordering
Email “UR8FH qty + target UR model” to ab@mooreplc.com (attn. May)
We’ll bounce back within 24 h with price, lead-time, DHL tariff code and a one-click PI—no spam calls, just stock and docs.
