High Current Three Phase Three Line Output Filter For Inverter

3 phase output EMC/EMI filter, it has excellent interference suppression for Dv/Dt. (1)Test Voltage ( 1min ): Line to Ground: 1450VAC. Line to Line: 2700VAC. (2)Insulation Resistance: Line to Ground: ≥3000Ω. Line to Line: ≥6000Ω. (3)Various connection optional: bolt and busbar terminals.



Hot selling high quality three phase three line output filter, bolt and busbar terminals are  optional. Our Factory is made up of 500 people, huge output can be finished every day. We have a technical team consist of 5 experienced engineers. If you are interested in our high current EMI filters, welcome to contact us.


Quick Details

Part No: Three Phase Three Line Output Filter For Inverter

Brand name: MCT

Rated Voltage: 250/440VAC

Custom made: Available

Rated Current: 5A~1200A

Logo: Can be customized

Operating Frequency: 50/60Hz

Packing: Carton, can custom

Temperature range : HPF 25/085/21

Shipping: Air, Ship, etc

Lead time: 25 days after payment

MOQ: Any quantity

Certification: ISO9001,ROHS,CE

OEM: Available


Part Information

Product Name: High Current Three Phase Three Line Output Filter For Inverter

Product features: (1)Over-voltage protection, reduce the electromagnetic interference of inverter. (2)Wide working current range from 5A to 1200A. (3)High quality components ensure the safety and reliability of filters. (4)As output filter for inverter, reduce the loss of inverter and motor choke.

Applications: Output filter for frequency inverter and converter, UPS, SMPS, three-phase motor drives.

Packing details: PP packing belt + Outer packing hard paper carton + inner packing pearl cotton or plastic tray

Samples time: 7-10 days for customized parts, 3-5 days for standard parts.


Product Details

Three Phase Three Line Output Filter For InverterCustomized three phase three line output filter


If you have any questions, please contact us or leaving your comments, we will give you fast reply.

Email: sales003@mycoiltech.com

Skype: sales003_125

QQ: 2783136957

Contact: Miss Lily Yu


Product Tags emi filter for inverter          inverter emi filter          emi filters for pv inverter          emc emi filter for inverter          inverter on emi          emi filter          emis filter          inverter on emi in gurgaon          inverter battery emi
