HOWO Sitrak 18m Aerial Ladder Rescue Fire Truck is a specialized emergency response vehicle engineered for high-rise firefighting and technical rescues. The Howo sitrak 18 m aerial ladder rescue fire truck carries a 4000-liter water tank and a mid-mounted single-stage centrifugal pump rated at 60L/s at 1.0MPa. Additional fire suppression capabilities include a 300kg dry chemical tank and foam proportioning system
Its primary function revolves around deploying an extendable 18-meter aerial ladder, engineered to reach elevated structures such as multi-story buildings, industrial complexes, or confined urban spaces where conventional equipment falls short.In fire suppression scenarios, howo sitrak 18 m aerial ladder rescue truck integrates a high-capacity water pump and foam projection system, capable of delivering targeted streams to extinguish flames at significant heights
● 30 years professional manufacturer experience.
● Good after-sell service
●Professinal engineer department
● Prompt delivery, any order is welcome.
● 24 month quality guarantee term
| Manufacturer |
Powerstar Trucks |
| Product Name |
Howo sitrak 18 m Aerial Ladder Rescue Fire Truck |
| Vehicle Brand Series |
Howo |
| Vehicle Model |
PST5180 XFPM60 |
| Chassis parameters |
Overall dimensions |
mm |
8580*2500*376 |
| Gross weight |
kg |
18500 |
| Curb weight |
15560 |
| Rated payload |
3050 |
| Suspension F/R |
mm |
1335/2230 |
| Wheel base |
4,500 |
| Driving type |
4*2 |
| Chiassis model |
QL1160AMFRY |
| Number of axles |
2 |
| Tire specification |
10.00-20-16PR,10.00R20-16PR,11.00R20-16PR |
| Number of Tires |
6+1 |
| Passengers in cab |
3+3 |
| Engine |
Engine model |
MC07H.35-60 ( MAN Engine) |
| Type of fuel |
Diesel |
| Displacement/power |
ml |
9856/257kw |
| Max speed |
Km/h |
110 |
| Emission standard(TAS) |
EURO 5 |
| Fire performance |
Tank capacity |
water tank capacity:2500kg foam tank capacity:300kg |
| Fire pump |
Brand:Shanghai Rongshen |
| Model: CB10/60-G |
| Low-pressure:30L/S |
| Medium-pressure:60L/S |
| Fire monitor |
Brand:China famous
|
| Model:CB10/60-G |
| Flow:50L/s |
| Water jet distance:≥60m |
| Foam jet distance:≥55m |
| Electronic alarm |
LY CJB-100-C24 |
| Alarm lamp |
LY TBD-XF-168LED |
Primary Applications of HOWO Sitrak 18m Aerial Ladder Rescue Fire Truck
-
High-Rise Rescue Operations
The HOWO Sitrak 18m Aerial Ladder Rescue Fire Truck is engineered for rapid evacuation and rescue missions in multi-story buildings. Its extendable 18-meter aerial ladder, equipped with a stabilized platform, enables firefighters to safely access victims trapped at elevations equivalent to six-floor structures.
-
Advanced Fire Suppression Capabilities
This vehicle integrates a high-capacity water pump and foam projection system, delivering up to 4,000 liters per minute to combat intense blazes. The ladder-mounted monitor nozzle can direct water or fire-retardant foam vertically or horizontally, suppressing flames in hard-to-reach areas such as rooftop installations or industrial complexes.
-
Multi-Functional Emergency Support
Beyond firefighting, the truck serves as a mobile command hub with auxiliary lighting, power generation, and equipment storage. Its integrated hydraulic rescue tools (e.g., spreaders, cutters) and 360-degree rotating platform assist in technical rescues during vehicular accidents or structural breaches.
HOWO Sitrak 18m Aerial Ladder Rescue Fire Truck operates through a systematic process to ensure efficient emergency response. Upon arrival at the scene, the vehicle is stabilized using hydraulic outriggers, which extend laterally to create a secure base, preventing imbalance during aerial maneuvers. The three-section, foldable ladder, constructed from high-strength alloy steel, is then hydraulically elevated to a maximum working height of 18 meters, capable of rotating 360 degrees with ±90° vertical articulation for precise positioning.
Operators in the insulated control cabin utilize a dual-control system, combining manual joystick operations with automated angle sensors, to align the ladder platform with trapped individuals. The ladder's load-bearing capacity (≥300kg) allows simultaneous rescue of multiple victims, while integrated safety rails and non-slip surfaces prevent secondary accidents.
During firefighting operations, the water cannon mounted on the ladder head discharges up to 4,000L/min, powered by the onboard 8,000L water tank and auxiliary fire pump. The dual-mode nozzle adjusts between focused jet streams for flame penetration and water mist for heat radiation reduction.
