Product Construction
1. Silver plated copper conductor 24 AWG 0.60 19x0.127
2. Dielectric of solid HFI 260, natural 2.5
3. Semi conductive carbon layer 2.53
4. Braid of silver plated copper Wire diam 0.10 3.0 Min coverage 90%
5. Inner jacket of HFI 260, natural 3.5
6. Braid of silver plated copper Wire diam 0.13 4.1 Min coverage 90%
7. Jacket of HFI 260, natural nom 0.35 ,4.8 Jacket marking with meter indication in contrasting colour,
HFI 260 insulated wires with Silver-plated or Nickel-plated conductors
High Radiation Resistance 109 Rad= 107 Gy
Communication systems 33ohm, 50oh, 75ohm RF cable, and upt/stp 100ohm, 120ohm 150ohm cable, and peek Armored Fiber Oifer cable.
Key Properties
• High continuous operating temperature 500°F (260°C)
• Outstanding abrasion resistance
• Excellent dielectric strength
• Exceptional chemical resistance
• Protects against corrosion Technical Notes
• Can be spliced using HFI 260 Annealed, solid, round bare copper wire and others
Radiation resistant HFI 260 Power cable,peek wire cable manufacturer,peek wire cable ,HFI 260 Power cable,Radiation resistant HFI 260 Wire.
