PEEK insulated wires with Silver-plated or Nickel-plated conductors
PEEK (polyetheretherketone) is a high-performance engineered polymer with one of the highest strength ratios with heat resistant properties. CITCABLE PEEK Insulated Wire results from the extrusion of PEEK over a wide range of solid and stranded conductors
We provide flat duplex insulated thermocouple wire consisting of a pair of conductors individually PEEK-resin insulated, and then PEEK-resin sheathed. In response to the needs of many of our customers, TypesJ, K and T, with 0.2-mm and 0.65-mm conductors, respectively. We can also make products compliant with Class 1.We can also make PEEK insulated, heat-resistant wire Cable
Type-K duplex insulated thermocouple wire
0.32 x1P K-2-PEEK
0.65 x1P K-2-PEEK
Type-T duplex insulated thermocouple wire
0.32 x1P T-2-PEEK
0.65 x1P T-2-PEEK
CITCABLE can insulate many different wire types with PEEK including: solid copper,silver-and-nickel-plated, stranded, square and rectangle profile wires, stainless stee,aluminum,and other custom types.
Features/Capabilities
• 3/0AWG to #36 AWG sizes (OD:0.3--20.0mm)
• Wall thickness ranging from (0.05 mm - 0.81 mm)
• 100% spark tested during extrusion
• Amorphous or crystalline PEEK Insulated Wire available
• Round, stranded, square and rectangular profiles available• Various types of wire available, including silver and nickel-plated wire as well as custom wire types
Looking for a halogen-free, flame-retardant material with unbeatable radiation resistance and safe to operate up to 260°C
Look no further than PEEK. A core insulating material in many of our cables, PEEK is ideal for demanding environments like nuclear power reactors or vehicle exhaust sensors
