Penetration-Resistant Inserts Flexing Tester GT-KB11
Product Introduction
Application:
Penetration-Resistant Inserts Flexing Tester is used to determine the flex resistance of penetration-resistant inserts for safety shoes.
|
Key Specifications
Model
|
GT-KB11
|
Bending stroke
|
33mm
|
Distance between
guide rod & fixture
|
70mm
|
Test speed
|
960 CPM
|
Test times
|
106 times
|
Power Supply
|
1∮AC220V 50HZ 5A
|
Dimensions(LxWxH)
|
Main machine: 40 x 70 x 50cm
Control stand: 25 x 23 x 27cm
|
Weight
|
230kg
|
Standards
|
EN ISO 20344 Section 5.9
AS/NZS 2210.2 Section 5.9
GB/T 20991 Section 5.9
ASTM F2412 section 11.7,
ASTM F2413 Section 5.7.5
CAN/CSA Z195 Section 5.3.2
|
Standard Accessories
|
Power line 1pcs
|
