Product features
Adopts aviation heat dissipation aluminum material and equipped with heat dissipation fan
Lightweight and portable, comfortable to hold, feature trigger switch
No assembly required, ready to use upon opening, with a fast response speed
Equipped with eight countermeasure modules, covering a wide range of aircraft types, effectively countering FHSS UAV
Technical parameters
|
F-08s
|
|
Size
|
500*280*88mm
|
|
Weight
|
4kg
|
|
Material
|
Aviation aluminum metal heat dissipation shell
|
|
Countermeasure frequency band
|
400M/900M/1.2G/1.4G/1.5G/2.4G/5.2G/5.8G
|
|
Operating distance
|
1.5km(Depending on working conditions)
|
|
Operation mode
|
Single-person handheld
|
|
Response time
|
≤3s
|
|
Expand & retraction time
|
≤15s
|
|
Battery life
|
Under typical working conditions of 90 minutes, plug and unplug the battery
|
|
Charging time
|
≤4h
|
|
Power supply
|
24V6Ah
|
|
Display screen
|
Real-time display of battery power status
|
|
Double switch
|
Eight independent frequency band buttons and trigger release switch
|
|
Indicator light
|
The frequency band indicator light is visible under strong light
|
|
Heat dissipation
|
Intelligent temperature control and built-in cooling fan
|
|
Working temperature
|
-40℃~60℃
|
|
The above parameters are for reference only. The detailed product parameters are subject to the actual delivery.
|
