RF-45 Low Loss RF PCB Stable DK High
Frequency High Performance Circuit Board
(Printed
Circuit Boards are custom-made products, the picture and parameters shown are
just for reference)
Hi
Everyone,
Today,
we’re going to talk about a type of Taconic ORCER Printed Circuit Board: RF-45
high frequency PCB.
RF-45 is ceramic filled PTFE resin laminate utilizing woven fiberglass as
reinforcement.
Typical Applications:
GPS
Antennas
RFID
Antennas
Satellite
Radio Antennas
Typical Value of RF-45:
|
Property
|
Test Method
|
Unit
|
Value
|
|
Material
|
/
|
/
|
RF-45
|
|
Dielectric
Constant
|
IPC-TM-650 2.5.5.6
|
/
|
4.5
|
|
Dissipation
Factor @ 10GHz
|
IPC-TM-650 2.5.5.5.1
|
/
|
0.0037
|
|
Moisture
Absorption
|
IPC-TM-650 2.6.2.1
|
%
|
≤0.04
|
|
Flexural
Strength (MD)
|
ASTM D790
|
psi
|
20700
|
|
Flexural
STRENGTH (CD)
|
ASTM D790
|
psi
|
19300
|
|
Peel Strength
(1 oz VLP)
|
IPC-TM-650 2.4.8
(Thermal Stress)
|
lbs/linear inch
|
10
|
|
Thermal
Conductivity
|
ASTM F 433
|
W/m/K
|
0.33
|
|
Volume
Resistivity
|
IPC-TM-650 2.5.17.1
|
Mohm/cm
|
1.4 x 108
|
|
Surface
Resistivity
|
IPC-TM-650.2.5.17.1
|
Mohm
|
3.3 x 106
|
|
CTE (x)
|
IPC-TM-650-2.4.41
(>RT -125℃)
|
ppm/℃
|
9
|
|
CTE (y)
|
IPC-TM-650-2.4.41
(>RT -125℃)
|
ppm/℃
|
13
|
|
CTE (z)
|
IPC-TM-650-2.4.41
(>RT -125℃)
|
ppm/℃
|
96
|
|
Flammability
Rating
|
UL94
|
/
|
V-0
|
Our PCB Capability (RF-45):
|
PCB Material:
|
Ceramic filled
PTFE Resin
|
|
Designation:
|
RF-45
|
|
Dielectric
constant:
|
4.5
|
|
Dissipation
Factor
|
0.0037 10GHz
|
|
Layer count:
|
Double Sided
PCB, Multilayer PCB, Hybrid PCB
|
|
Copper weight:
|
0.5oz (17 µm),
1oz (35µm), 2oz (70µm)
|
|
PCB thickness:
|
20mil (0.508mm),
25mil (0.635mm), 31mil (0.787mm), 62mil (1.575mm), 125mil (3.175mm)
|
|
PCB size:
|
≤400mm X 500mm
|
|
Solder mask:
|
Green, Black,
Blue, Yellow, Red etc.
|
|
Surface finish:
|
Bare copper,
HASL, ENIG, Immersion silver, Immersion tin, OSP etc..
|
Other Avaialbe PCB Material:
FR-4 Tg>135, High Tg>170 FR-4 ( S1000-2M, TU-872 SLK, TU-768,
IT-180A etc.)
Rogers RO4350B, RO4003C, RO4730G3, RO4360G2, RO3003, RO3035, RO3006,
RO3010, RO3210, RO3203, etc.
Rogers RT/duroid 5880, RT/duroid 5870, RT/duroid 6002, RT/duroid 6010,
RT/duroid 6035HTC etc.
Rogers TMM4, TMM10, Kappa 438 etc.
PTFE F4B (DK2.2, DK2.65, DK2.85, DK2.94, DK3.0, DK3.2, DK3.38, DK3.5,
DK4.0, DK4.4, DK6.15, DK10.2)
Taconic TLX-0, TLX-9, TLX-8, TLX-7, TLX-6, TLY-5, TLY-3, RF-35TC,
TLF-35, RF-60A, RF-60TC, RF-35A2, TRF-45 etc.
AD450, AD600, TC350 etc.
Nelco N4000, N9350, N9240
Metal core PCB, 1W/MK-3W/MK material
Flexible PCB, Megtron 6 (M6) R-5775G
Our PCB Services:
PCB prototypes
Mass volume production
Single sided PCB
Double sided PCB
Multilayer PCB up to 32 layers
Heavy copper PCB
Hybrid PCB
Impedance controlled PCB
Via in pad PCB
Ball grid array (BGA) PCB
Blind via PCB
Countersink holes, half hole, press-fit hole
Quick turn-around (QTA) Delivery
No Minimum Order Quantity (MOQ)
Door to Door shipment service
