Rotable Head 4-axis Desktop Robotic Soldering Machine
1. The desktop robotic soldering machine is applicable for different products, soldering temperature can be set freely.
2. The soldering iron unit can be multi-directionally adjusted, which can protect the PCB and components from damage.
3. Numerically controlled temperature(static air condition: +-1 degree)
4. With the handheld teaching pendant, the programming is simple and easy to learn.
5. In the soldering process, the solder tip has rapid heat recovery and a long life span.
6. This desktop robotic soldering machine has 4 axis ;with 360 rotation R aixs, workable for difficult soldering jobs.
SPECS:
|
Model
|
SMTSR114
|
|
Dimension
|
880*700*830mm
|
|
Weight
|
70Kg
|
|
Control
|
PLC
|
|
Programming
|
Teaching box
|
|
Driving mode
|
Stepper motor
|
|
Stroke
|
300(X)x300(Y)x80(Z)x360°(R)
|
|
Soldering head
|
1
|
|
Repeatability
|
±0.02mm(X/Y/Z)
|
|
Temp. Range
|
0-500℃
|
|
Solder Wire Spec
|
￠0.3-1.6mm
|
|
Number of axes
|
4
|
|
Working pressure
|
0.4~0.6Mpa(No water mist)
|
|
Power
|
AC110V/220V 300W
|
|
Display
|
LCD
|
;
FEATURES:
1. ;Flexible and diverse soldering methods, with spot welding, drag welding (pull welding) and other functions.
2. The mechanical arms of the equipment are all aluminum profiles, which are not deformed, rusted and stable.
3. Device writing work program can be point-to-point, block-to-block copy, shorten the programming time.
4. The device has an automatic cleaning function, to a certain extent stabilize the quality of solder processing and extend the life of the soldering iron tip.
5. Multi-axis linkage manipulators, all adopt precision stepping motor drive and advanced motion control algorithms to effectively improve motion positioning accuracy and repeatability.
6. This machine is double head and single working place,we accept the double head and double working place and so on.
APPLICATIONS:
This 4-axis Desktop Robotic Soldering Machine is suitable for automotive electronics, digital, electronic, electro-acoustic, LCD, circuit board and other production industries, connectors, networks, transformers, cable, FPC / COF soldering, computer motherboards, CABLE, speakers and motors high quality soldering.
CONFIGURATION:
1. ;Handheld teach programmer
2. ;Heating controller
3. ;Broken tin controller
4. ;Soldering tip
5. ;Tin out components
6. ;Smoke purification filter system (optional)
SPARE PARTS AVAILABLE:
1. Customized soldering tips
2. Heater
3. Customized fixture
4. Solder wire
5. Soldering head set
; ;
; ;
COMPANY PROFILE:
2008, Dongguan factory established, and start producing standard v-cut PCB separators and hot bar soldering machines.
2010, Our products are widely sold in local market.
2012, Start producing customized v-cut depaneling and PCB router.
2014, ;Expand our sales team for providing better service to more customers.
2015, Start manufacturing laser depaneling machines.
2017, Start manufacturing ;soldering robot and screwdriver machines.
2018, HK company established.
2019, Huizhou factory established, due to expansion.
2020, Business expansion again, products covering PCB depaneling, PCB soldering, screwdriver system, etc. ;
2021, Our machines cover all Chinese market and also popular in America, Europe, South Asia, East Asia, etc.
OUR SERVICE:
1. Guarantee for 12 months.
2. Maintenance for whole life.
3. We ;will ;provide ;the ;consumable ;parts ;at ;an ;resonable price.
4. 24 ;hours x 7days online ;service, ;free ;technical ;support.
5. Machine ;has ;been tested before ;delivery.
6. We ;have ;manual ;instruction ;and Guiding ;Videos for installation, ;operation ;and machine's ;using ;and ;maintenance.
7. Oversea on-site installation and trainning is available.
8. Vacuum & wooden case packaging is provided free of charge for sea shipment.
