Thermocouple wires are cables that are manufactured with two different metals, and are used to measure temperature. Different “thermocouple types” are used to measure various temperatures. The insulation on thermocouple wires are color coded for identification purposes.
These wires come in “Thermocouple Wire Grade,” and “Extension Grade.” Thermocouple Wire Grade wires are used to make the sensing point, or the probe part of thermocouples. The Extension Grade wires are used to extend thermocouple signals from a probe, then back to the instrument. Thermocouple wires may be used as an extension wire, but the same does not apply vice-versa.
Insulation materials include high temperatures to low temperature:
PFA/PEEK/PEI/TPI ----260C
FEP/XLETFE/VITON/FKM/SILICONE ---200C
ETFE/XPVDF/E-CTFE ---150C
XLPE,EPDM,RUBBER ----150C
Key Features
- Halogen free and low toxicity
- Excellent radiation resistance
- cable outstanding and excellent abrasion resistance, dielectric strength, chemical resistance, thermal endurance in long
- Protects against corrosion
Application
Temperature Sensor Cable (Thermocouple, PTC/NTC/Heating/RTD)
K type 30awg Flat PEEK Thermocouple Wire
K type 30awg Flat Teflon Thermocouple Wire
N type 20awg Teflon Thermocouple Wire
NTC 30awg Nickel plated Silver PEEK wire OD:0.5MM
316L plated Silver Heating Wire 0.45MM
Tungsten Wire 0.12mm, 0.17mm 0.3mm
Cr20Ni80 Wire 0.12mm, 0.17mm 0.3mm
30awg 3c RTD Sensor Cable
20awg 3c RTD Sensor Cable
Karma Alloy Sensor Cable
