AS 1577 Kwikstage Scaffolding Steel Planks

Kwikstage Scaffolding Steel Plank is a kind of plank which is designed and fabricated as per the Standard requirement of Australia/New Zealand AS 1577. It is made by 1.8mm or 1.5mm steel plate and hot dip galvanized. The planks are no hooks at both ends and to be installed onto the scaffolding transoms.


  • MaterialSteel

Kwikstage Scaffolding Steel Plank, without hooks, t=1.8mm

Code Description Material Size Weight (kg) Weight (lbs)
KS.SP5.22303 3.03M Steel Plank Plate t=1.8mm; Q235 225x65x3030mm (10') 18.60  41.01
KS.SP5.22242 2.42M Steel Plank 225x65x2420mm (8') 14.60  32.19
KS.SP5.22181 1.81M Steel Plank 225x65x1810mm (6') 11.20  24.70
KS.SP5.22150 1.50M Steel Plank 225x65x1506mm (5') 9.50  20.95
KS.SP5.22125 1.25M Steel Plank 225x65x1250mm (4'2") 7.80  17.20
KS.SP5.22120 1.20M Steel Plank 225x65x1200mm (4') 7.50  16.54
KS.SP5.22090 0.90M Steel Plank 225x65x896mm (3') 5.85  12.90
KS.SP5.22074 0.74M Steel Plank 225x65x740mm (2'6") 4.69  10.34


Features:

The plank is no hooks (plain end).

Sizes of Plank: 225mm (W) x 65mm (H) x L, or 230mm (W) x 63mm (H) x L

Thickness of Plate: 1.8mm is recommanded, 1.5mm is also available by request.

Finishing: Hot dip glavanized or pre-galvanized is recommanded, powder coated, painted is also available.

Quality Standard: AS 1577
