HStars screw type water source heat pump

40STD Series flooded type water source heat pump can reach the highest COP is 6.0, the lowest chilled water temperature is 5℃ and the highest water outlet temperature is 50℃



Profile----HStars screw type water source heat pump

40STD Series flooded type water source heat pump can reach the highest COP is 6.0, Cooling capacity is from 106 kw to 3875kw, heating capacity from 30kw to 4145kw, the lowest chilled water temperature is 5℃, and the highest water outlet temperature is 50℃. Units are suitable for industry and commerce building with cooling and heating need


1. High Efficiency---HStars screw type water source heat pump

*The unit adopts twin screw type compressor, match with self-produce high efficiency condenser and evaporator, International brand expansion valve is applied, to ensure the performance of the unit reach the national primary energy saving standard.
*With patent heat recovery option, heat reclaimed can be 30% to 100% of cooling capacity in cooling mode, get free hot water for around a year. Free hot water can be up to 70℃
*Heat reacovery do not use any energy, on the other hand increases unit efficiency about 5%.


2. Reliability and Stability---HStars screw type water source heat pump
*8 safety protection devices are installed, ensure the chiller operation well.
* The unit is using an efficient oil return device, therfefore the unit run safety and stable.
*All units are 100% tested by National Test Laboratory to ensure the performance


3. Intelligent Control--HStars screw type water source heat pump
* Chiller adopted microcomputer with touch screen control system, provides the simplest and completest operation interface, timely feedbacks all maintenance information

4. Special design---HStars screw type water source heat pump
Various refrigerant available: R22, R407c, R134a
* The unit can connect to the center control system wich feedback the operational status and achieve remote service
Hstar flooded type screw type water source heat pump
