Water-Cooled Low Temperature Ice Skating Rink Chiller Unit
Profile
-
The refrigeration system of indoor ice skating
rink usually adopts two refrigeration methods: direct expansion and indirect
cooling. Direct expansion adopts "Hstars"
brand condensing unit; indirect cooling adopts "Hstars" brand screw
type low-temperature chiller, Glycol is used as a refrigerant to form ice on
the rink.
-
At present, uses indirect cooling methods is more popular in the ice rink market. The cooling host should select more than two, one of which can meet the cooling under normal load conditions. When the conditions are relatively bad or the operating host needs to be repaired, the other one can replace the operating host to work.
-
Brand: H'Stars
-
Cooling capacity range: 25Kw-2045.30Kw
-
Applications: Ice rink, Food processing, chemical, refrigeration and various industrial and commercial cooling systems with special low temperature requirements.
Unit Parameters
-
Cooling capacity range: 25Kw-2045.30Kw
-
Freezing aqueous solution temperature range: -45°C ~ 10°C
-
Fields of application: Ice rink, Food processing, chemical, refrigeration and various industrial and commercial cooling systems with special low temperature requirements.
Type selection of refrigerating mainframe
-
The hardness of the ice surface determines its hardness.
Generally speaking, the hardness of the ice surface at -5 degree can meet the
requirements. To meet the requirements of ice temperature -5 C, the ethylene
glycol solution in pipe of the ice field is set at -15 C.
-
At present, “Hstars” brand has both water cooled screw-type low
temperature water chiller and air-cooled screw-type low temperature water
chiller to be choosen, also be used without the standard selection of water pump
and expansion water tank. it can work immediately at site after Connect pipe
and electricity, It can also increase the heat recovery device, make the hot
water at the same time, which will improve the economic efficiency.
Schematic Diagram
Main components of water-cooled screw type chiller unit
