1100 Degree 7.2L Volume Laboratory Inert Gas Muffle Furnace
SPECIFICATIONS
The TOB-KBF11Qlaboratory inert gas muffle furnaceadopts Electric resistance wire as heating element with fast temperature rising. (up to 1000degrees within 30mins). 40 segments programmable temperature controllers are installed with 6 groups of PID adjustment.
ThisAtmosphere muffle furnaceis the ideal laboratory equipment for universities, research institutes, industrial and mining enterprises to do atmosphere intering , Atmosphere reduction.
|
Model
|
Dimension
(D*W*H)
|
Power
|
Voltage
|
Max Heating Temperature
|
|
TOB-KBF11Q-I
|
300*200*120mm
|
2.5kw
|
AC110V/220V
|
1100℃
|
|
TOB-KBF11Q-II
|
300*200*200mm
|
4kw
|
|
TOB-KBF11Q-III
|
300*250*250mm
|
5kw
|
|
TOB-KBF11Q-IV
|
400*300*300mm
|
9kw
|
380V
|
|
Heating element
|
Electric resistance wire
|
|
Temperature controller
|
40 program temperature control system,
With over temperature, broken accidentally protection function,
6 groups of PID adjustment
Control precision of + / - 1 ℃
|
|
Furnace chamber
|
Polycrystal alumina fiber
|
|
Pressure measure system
|
Pressure gauge
|
|
Air intake control
|
Flow meter
|
|
Air source
|
H2, Ar, N2, O2, CO, Etc.
|
|
Warranty
|
One year limited warranty with lifetime support
|
