100L Capacity Vacuum Planetary Mixer Machine For Lithium Battery Productiong Line
SPECIFICATIONS
Thevacuum planetary mixeris excellent for preparing LiCoO3, LiFePO4, Phosphors and ceramic slurry without gas bubble. And the processed material results in the better dispersion and uniformity.
1, application: vacuum stirring dispersion mixing all kinds of low, medium and high viscous material, such as various types of batteries, engineering/electronic pastes adhesive/sealant, etc., and the finished products with fluid (mostly for non-newtonian fluid) exist.
2, works theory : the low speed impeller make the material produces strong kneading movement and interference and up and down/circular motion around;High speed dispersion plate produces strong mechanical and hydraulic shearing action, can make full/depth scattered material;So as to ultimately ensure that materials are fully dispersed and mixed evenly (mixed).
|
Model
|
VacuumPlanetaryMixer TOB-XFZH200
|
|
Low speed
revolution and rotation
|
Frequency conversion
motor power
|
15KW
|
|
variable-frequency drive
|
15KW
|
|
Revolution speed
|
0～65rpm
|
|
Revolution speed
|
0～25rpm
|
|
High speed dispersion
|
Frequency conversion
motor power
|
22KW
|
|
variable-frequency drive
|
22KW
|
|
Dispersion plate
|
Diameter : DIN160
Speed : 0～2800rpm
|
|
Mixing barrel
|
Dimension
|
Dia.750mm×H 650mm
|
|
Capacity
|
Design capacity :287L
Working capacity :200L
|
|
Materials
|
Sus304 stainless steel, with thickness 5mm
|
|
Vacuum degree
|
-0.098MPa, no less than -0.085 MPa after 24hours
|
|
Voltage supply
|
Operating voltage 380 v / 50 hz / 3 phase,
Control voltage 24 v DC
|
|
Weight
|
About4500KG
|
|
Dimension (L*W*H)
|
2400×1200×2850（mm）
|
PRODUCT DISPLAY
