Model

1-2 Series Battery Pack Test Equipment  TOB-W602

Source voltage

AC110V/220V, 50/60HZ

Power

10-50W

Warranty

One Year limited warranty with lifetime support

Dimension (L*W*H)

290mm(L)*270mm(W)*100mm(H)

Weight

4kg

Function

Range

Resolution

Accuracy

Voltage test (V1)

0—5 V

0.001V

0.2% + 3

0—10 V

0.01V

0.3% + 5

Charging   (CHA)

50—2000mAh

1mA

2% + 3

Discharging

50—200mAh

1mA

1% + 5

Over discharging current (OVC)

0—20 A

0.01A

2% + 3

Internal Impedance (IMP)

0—999 mΩ

1mΩ

±1mΩ

Short-circuit protection (SPT)

0—99.9 mS

0.1mS

2% + 3

Thermistor (R1/R2)

0—999.9 kΩ

0.1kΩ

2% + 3

Capacity

0—9999 mAH

1mAH

3%

1 Standard exported package : Internal anticollision protection, external export wooden box package

2 Shipping by express, by air, by sea according to customer's requirements to suggest the most suitable shipping mode

3 Responsible for the damage during shipping process, change the damage part for free

4 Supply with suitable voltage input and power plug according to customer's country requirements.

1 We supply machines with battery technology support.

2 We can also supply a full set of materials for lithium battery including polymer battery, cylinder battery, mobile phone battery, EV battery.

3 We can also supply a full set of lithium battery equipment for lab research, pilot scale research and production line.

4 We can also supply a full set of battery technology for battery design, research and producing.
