Electric Liquid Injection Pump
SPECIFICATIONS
Functional overview
The machine makes use of stepping motor to drive rotation motion and reciprocating motion of ceramic plunger rod.
Rotation motion is used for changing valve direction, and reciprocating motion is used for liquid inlet and outlet
so as to reach the purpose of controlling fluid accurately.
Functional characteristics
1.Adopt anti-corrosion and special high wear-resisting ceramic pump head.
2.Assembling, disassembling or cleaning of pump head is convenient and quick.
3.Select speed. Number of turns is continuous and adjustable.
Technical parameters
|
Power source
|
AC220V/50Hz Power: 0.5kW
|
|
Injection accuracy
|
±0.1%
|
|
The calibration of the injection liquid is rough,
and the precision is controlled by the program
|
|
Injection volume adjustment,
by setting the number of pulses to achieve precision adjustment
|
|
Overall dimensions(Lx W x H)
|
380 x 130 x 120mm
|
|
Weight
|
13kg
|
