Horizontal power battery needling testing machine
SPECIFICATIONS
1.Technical requirements
|
Model
|
Horizontal Power battery needling testing machine
TOB-BE-AP-9002D
|
|
Pressure range
|
1000N~20000N Customized
|
|
Dimension
|
W2400*D1000*H1200MM
|
|
Weight
|
500kg
|
|
Testing space
|
W1000*D500*H500MM Customized
|
|
Power
|
2500W
|
|
Needling mode
|
Oil pressure
|
|
Needling force
|
±1% accuracy
|
|
Needling speed
|
10-40MM/S, adjustable,
|
|
Needling speed error
|
±0.1MM/S
|
|
Unit Conversion
|
Kg/N/Lb
|
2.Standard configuration
|
Needling host
|
A set
|
|
Protective case
|
A set
|
|
Needling holder
|
A set
|
|
Big battery fixing clip
|
A set
|
|
White steel needle/ Tungsten steel needle
|
A set
|
|
Surveillance camera system（Optional）
|
A set
|
|
Voltage acquisition system（Optional）
|
A set
|
PACKAGE AND SHIPPING
|
1 Standard exported package : Internal anticollision protection, external export wooden box package
2 Shipping by express, by air, by sea according to customer's requirements to suggest the most suitable shipping mode
3 Responsible for the damage during shipping process, change the damage part for free
4 Supply with suitable voltage input and power plug according to customer's country requirements.
|
SERVICES
|
1 We supply machines with battery technology support.
2 We can also supply a full set of materials for lithium battery including polymer battery, cylinder battery, mobile phone battery, EV battery.
3 We can also supply a full set of lithium battery equipment for lab research, pilot scale research and production line.
4 We can also supply a full set of battery technology for battery design, research and producing.
|
