Portable Internal Resistance Tester for All Batteries 0 - 20V With Charging Adapter
SPECIFICATIONS
TOB-BVIRBattery internal resistance testercan be used for measuring theInternal Resistance and Open Circuit
Voltage of almost all of the commercial batteries such as Secondary battery, Lead acid battery, Nickle cadmium, Nickle-metal Hydride and Li-ion battery.
|
Model
|
Battery Internal Resistance Tester TOB-BVIR
|
|
Measuring Method
|
AC 4 terminals
|
|
Voltage
|
Voltage Measurement
|
0～20V
|
|
Precision
|
0.1%
|
|
Resistance
|
Resistance Measurement
|
20mΩ\200mΩ\2000mΩ
Auto/Manual Switch
|
|
Precision
|
0～200mΩ
|
1%
|
|
201mΩ～2000mΩ
|
3%
|
|
A/D
|
12 Digits SAR Comparing
|
|
Testing
|
Sampling Frequency
|
1KHz
|
|
Sampling Rate
|
1000 times/S
|
|
Current
|
< AC 20mA
|
|
Response
|
Refresh 5 times/S
|
|
Comparator
|
On/Off (Manual)
|
|
Number of Comparator
|
10Sets
|
|
Data Storage
|
100,000 Entries
|
|
Calibration
|
A 100 mOhm Resistor in Standard Package for Calibration
|
|
Dimension
|
W*D*H: 120*75*25(mm)
|
|
Weight
|
200g
|
|
Suggested Environment
|
10℃~ 40℃ in temperature and 30% ~ 80% RH in Humidity
|
REFERENCE PICTURE
Test polymer battery
PACKAGE AND SHIPPING
|
1 Standard exported package : Internal anticollision protection, external export wooden box package
2 Shipping by express, by air, by sea according to customer's requirements to suggest the most suitable shipping mode
3 Responsible for the damage during shipping process, change the damage part for free
4 Supply with suitable voltage input and power plug according to customer's country requirements.
|
SERVICES
|
1 We supply machines with battery technology support.
2 We can also supply a full set of materials for lithium battery including polymer battery, cylinder battery, mobile phone battery, EV battery.
3 We can also supply a full set of lithium battery equipment for lab research, pilot scale research and production line.
4 We can also supply a full set of battery technology for battery design, research and producing.
|
