Horizontal Computer Control Power Battery Crush Testing Machine
SPECIFICATIONS
1.Technical requirements
|
Model
|
Horizontal Computer Control Power Battery Crush Testing Machine
TOB-BE-AP-6045
|
|
Source voltage
|
3∮5W 380V 50HZ 5000W
|
|
Dimension(W*D*H)
|
2500W*1000D*1000H MM
|
|
Weight
|
1500kg
|
|
Max pressure
|
10t,20t, 50t,80t
|
|
Battery size
|
500W*500D*500H MM，Customized 1000*1000*1000 or bigger
|
|
Force error
|
±1%
|
|
Drive mode
|
Electro-hydraulic servo drive
|
|
Extrusion speed
|
0.1~500MM/S(Adjustable)
|
|
Unit Conversion
|
kgf，lbf，N，KN，Kpa，Mpa
|
|
Stroke Resolution
|
0.005mm
|
|
Data collection frequency
|
200times/S
|
|
Signal transmission mode
|
RS 232 or USB
|
|
Test hole
|
On the left,50mm diameter hole attached a stainless
steel lid
|
|
Visual window
|
Double-proof glass800*300MM and affixed with
explosion-proof film, and with steel mesh
|
2.Standard configuration
|
Host
|
1set
|
|
Brand computer
|
1set
|
|
Color Inkjet Printer
|
1set
|
|
Surveillance camera system
|
1set
|
|
Voltage acquisition system
|
1set
|
|
8 channels temperature acquisition system
|
1set
|
|
Special - shaped extrusion plate
|
1set
|
|
Round-shaped extrusion plate
|
1set
|
|
Operating Instructions
|
1set
|
|
Factory inspection report
|
1set
|
