Intelligent Volumetry Method Karl Fischer Titrator For Battery Electrolyte Moisture Analysis
SPECIFICATIONS
1 TOB-AKF-2010karl fischer titratoris an Intelligent moisture tester adopting volumetry method. it is mainly used for scientific research, produce, and education field, with high accuracy and simple operation.
2 It can be used for analyzer water in many industries fields such as Medicine, organic solvents, industrial salt, petrochemical industry, chemical fertilizer, agricultural medicine, dyes, food and beverage, surface active agent, cosmetics and so on.
3 Thiskarl fischerused for lithium battery industry mainly used for powder materials and electrolyte moisture analyzer
|
Model
|
Volumetry Method Karl Fischer Titrator TOB-AKF-2010
|
|
Testing range
|
0.001-100%
|
|
Measuring resolution
|
1ug
|
|
Measuring repeatability
|
99.7%, (10mg)
|
|
Max error
|
±0.3%
|
|
Testing time
|
Average 3min
|
|
Date storage
|
100000, can be expanded
|
|
Buret
|
Optional 20 ml, 10 ml and 5 ml high precision measuring tube component,
attached to the uv radiation shield
|
|
Titration control precision
|
0.5u-0.1ml can be chosen
|
|
Electrode connect
|
Double platinum electrode
|
|
Display mode
|
LCD, Chinese or English
|
|
Data interface
|
RS-232C, USB, WEB
|
|
Working humidity
|
≤80%
|
|
Working temperature
|
5-40℃
|
|
Source voltage
|
220V / 50HZ, can work with voltage transformer
|
|
Power
|
50W
|
|
Dimension(L*W*H)
|
400*350*280mm
|
|
Weight
|
5.5kg
|
