Lithium Ion Battery Copper Foil 10um

Lithium Ion Battery Copper Foil 10um.



Lithium Ion Battery 10micron Copper Foil


SPECIFICATIONS



Width:300mm  Lenght: 383m Thicness:10um Mode:T-C10

Copper foil for battery anode substrate

Item

Data

width (mm)

300mm

Thickness (um)

10

areal density (g/m2)

85-90

Purity(%)   More than 99.9%

Cu ≥99.9%

Fe < 0.0010%

Bi < 0.00020%

Pb < 0.0005%

Tensile strength (MPa)

≥400

Normal elongation(%)

3.72

High temperature Tensile strength180℃(MPa)

≥150

High temperature elongation180℃(%)

2

Anti oxidization(180℃ Heating 1h)

No oxidation of points on the surface,The color does not change,Copper

 foil without fracture

Surface roughness(um)Rz

Drum side(um)

Less than 0.3

Matte side(um)

Less than 3.5

Surface tension(dyne/cm)

Drum side

65

Matte side

65

Coating performance

Cu foil with uniform tension on both sides, slurry coating uniformity
