High Speed Automatic Specific Surface Area Instrument With Four Testing Position
SPECIFICATIONS
The TOB-BETSpecific Surface Area Instrumentis used for Battery materials, magnetic materials, catalyst, adsorbent, cement, ceramic raw materials, metallurgical raw materials, carbon, silica, inorganic materials, coatings, abrasive, nano materials, medicine powder, rare earth, porous material, composite material powder and granular material specific surface area measurement.industry, building materials, coatings, abrasive and other industries.
|
Model
|
Specific Surface Area Tester TOB-BET-04
|
|
Voltage supply
|
AC 110V/220V 50HZ/60HZ±10%
|
|
Power
|
300W
|
|
Warranty
|
One year limited warranty with lifetime support
|
|
Technical principle
|
Adopt dynamic nitrogen adsorption method, using gas chromatography, cryogenic adsorption principle,
adopt high sensitive sensor, double source dynamic test method, use helium as carrier gas,
nitrogen gas is adsorbed on the solid surface as a test gas For different sample analysis
|
|
Measuring range
|
0.1m2/g～3500 m2/g
|
|
Measure time
|
5-7min/sample, Can test four samples every time
|
|
Measuring accuracy
|
＜ ±1％
|
|
Testing method
|
Single point test, contrast test, multi point (BET) analysis.
|
|
Dimension(L*W*H)
|
480*630*370mm
|
