Tap Density Tester For Lithium Battery Powder Materials Research
SPECIFICATIONS
1 Thetap densityis an important index of powder materials quality. Tap density measurement, refers to a certain amount of powder into a vessel, vibration under certain conditions, until the container volume will no longer reduce, read out the powder volume, and then use the powder weight divided by the volume to get vibration compaction density.
2 TOB-TDT-JZ-1 type powder compactiontap density instrumentapplicable to the pharmaceutical, battery materials, electronic materials, ceramics, powder coating, metal powder, food, chemical industry, building materials, coatings, abrasive and other industries.
|
Model
|
Tap Density Tester TOB-TDT-JZ-1
|
|
Voltage supply
|
AC 110V220V 50HZ/60HZ±10%
|
|
Power
|
50W
|
|
Warranty
|
One year limited warranty with lifetime support
|
|
Technical principle
|
Tap density refers to the powder in the container will be filled by the vibrated density
under specified conditions
|
|
Measure time
|
5-60min/time, Can test 3 samples a time
|
|
Vibration frequency
|
60times/min
|
|
Oscillation Amplitude
|
50mm
|
|
Measuring accuracy
|
＜ ±1％, when test they drum automatically in a cycle of rotation angle,
ensuring the noodle was the level of the state,
so as to ensure the accuracy of measurement of the height of the noodle
|
|
Sample cylinder
|
Stainless steel material, Outside diameter : 19.7mm,
Inner diameter : 16.25mm, Height : 80mm, Volume : 16.6ml
|
|
Dimension(L*W*H)
|
400*280*280mm
|
