Press brake 4v dies with V16,V22,V35,V50

Standard 4v dies, V16,V22,V35,V50 with 85 degree and 88degree. the size is 60*60*835mm, material 42CrMo4 .the weight is 15.6kg. the material is 42CrMo4, hardness is HRC47+/-3.

Press brake rolla-v dies without scratch

Press brake rolla-v dies without scratch, it's best to put the film on the workpiece surface when you bend. and we will recoomend the suitable roll-v die size for you according to the plate you bend.

Offset Punch and Die Set / bending tools

Also known as Z bends or Joggles, the Offset punch and die set is able to make two bends at the same time. This is the solution for applications requiring materials to be joined together or when you need to make a second bend that will not interfere with the first bend.

Press Brake Hemming Dies With Spring For Flatten

Press brake hemming dies with spring for flatten, we can change the v opening according to the customer's bending thickness. Bending step: 1.bending angle first； 2.flatting.

Press brake wingbend dies Tension Spring Series Non-indentation Die for Press Brake

Press brake wingbend dies without scratch, it's best to put the film on the workpiece surface when you bend. and we will recoomend the suitable roll-v die size for you according to the plate you bend.

China Good Quality Gooseneck Press Brake Dies Tooling

The gooseneck punch size: 160*56*835mm, 85degree. the material is 42CrMo4, hardness is HRC47+/-3, and height 130mm, the weight is 22.4kg. Can be made according to customer's request.

TRUMPF / Wila style press brake punch / bending tools

The punch size is 256*85*500mm, 86degree, the material is 42CrMo4, the weight is 33.5kg. Welcome to explore our quality press brake tooling and contact us for professional service!

Drive with Motor for Crowning Table

The motor of the press brake crowing table is the core driving component of the mechanical compensation system, and its functions are: 1. Drive the compensation wedge block to achieve precise deflection compensation; 2. Improve compensation efficiency and stability; 3. Integrated intelligent control function.

Low Cost High Accuracy Bystronic-beyeler Compatible blades holder for Press Brakes H = 135mm

The punch size is 135*28*500mm, 85degree, the material is 42CrMo4, the weight is 7kg. Welcome to explore our quality press brake tooling and contact us for professional service!

Jaminnar Brand Press Brake Tool - Trade Promotion: Standard Model Forging Mould Clamp

The punch can be quickly installed and removed from this clamping tool, it reduce the worker's time. and we can make quick clamp tools, ordinary clamp tools and hydraulic clamping.

H13K Shearing Machine Cutting Blade Sheet Metal Guillotine Shear Blade

Shearing blades are the core component of the shearing machine, used on the shearing machine for cutting the sheet metal. There are blades for your reference: 1100*80*20mm, 1300*80*20mm, 1100*100*25mm, 1300*100*30mm, 3100*100*30mm and others. the blades material are: Cr12MoV 、H13K、H13、6CrW2Si、9CrSi，etc. hardness: HRC52-60.

Machinery manufacturing of Aerospace engine

Aerospace engine parts are high quality requirements, GT combined with CNC machining and rapid prototyping to perfectly achieve customer needs

Jaminnar Shear Blades for Cutting All Kinds of Sheet Metals

Shearing blades are the core component of the shearing machine, used on the shearing machine for cutting the sheet metal. There are blades for your reference: 1100*80*20mm, 1300*80*20mm, 1100*100*25mm, 1300*100*30mm, 3100*100*30mm and others. the blades material are: Cr12MoV 、H13K、H13、6CrW2Si、9CrSi，etc. hardness: HRC52-60.

Rapid prototyping of robot components

GT’ combined CNC machining, injection molding process to help customers complete their robot design concept

Jaminnar Standard Type Punches LVD Gooseneck Punches, LVD Mold for Press Brake Machines

LVD press brake tooling is a matching tool designed specifically for LVD brand CNC bending machines. It has the characteristics of high precision, wear resistance, and strong adaptability, and is widely used in the field of sheet metal processing. We can customize comprehensive punch and dies, and European LVD tooling. This cnc punch press tooling includes punches, dies, adapters. It supports segmented, solid length, and half-length sizes. we have a wide range of LVD press brake punch and die selections. LVD tooling can deliver a quick, easy, and flexible job with advanced designs.

CNC Machining for network switch components

GT combines CNC machining and sheet metal process to help customers save product development time,Ensure product quality.

European Amada Press Brake Gooseneck Punch 115mm Tooling with Best Price and Quality

The gooseneck punch size: 115*45*835mm, 85degree. the material is 42CrMo4, hardness is HRC47+/-3, and height 130mm, the weight is 12.8kg. Can be made according to customer's request.

Component of Energy-storage power sources

GT combines CNC machining and rapid prototyping to help customers save product development time.

Custom Punch & Die Solutions · R50 Radius Polyurethane (PU) Elastomer Die Set for CNC Press Brakes.

Polyurethane (PU) elastomer die set is a composite mold system that combines a metal frame and polyurethane elastomer. It can effectively absorb the impact force during sheet metal stamping or forming, reduce the wear of metal molds, and protect the surface of sheet metal parts from scratches.. for the angle and V opening, we can make it according to your bending request.

42CrMo Steel PU Elastomer Punch & Dies for Amada CNC Press Brake

Polyurethane (PU) elastomer die set is a composite mold system that combines a metal frame and polyurethane elastomer. It can effectively absorb the impact force during sheet metal stamping or forming, reduce the wear of metal molds, and protect the surface of sheet metal parts from scratches.. for the angle and V opening, we can make it according to your bending request.

Custom Precision Press Brake Dies OEM Sheet Metal Bending Solutions

The punch size: 110*26*835mm, 60degree. the material is 42CrMo4, hardness is HRC47+/-3, and height 110mm, the weight is 9kg. Can be made according to customer's request.

TRUMPF style press brake punch / bending tools

The punch size is 256*60*500mm, 86degree, the material is 42CrMo4, the weight is 25kg. for the angle and radius, we can make it according to your bending request. Welcome to explore our quality press brake tooling and contact us for professional service!

Bystronic-beyeler Press Brake Tooling Upper Punches for Bending Sheet Metal

The punch size is 175*20*515mm, 30degree, the material is 42CrMo4, the weight is 12.8kg. for the angle and radius, we can make it according to your bending request. Welcome to explore our quality press brake tooling and contact us for professional service!

Jaminnar Standard Punch of Beyeler Type Press Brake Tooling

The punch size is 175*30*515mm, 85degree, the material is 42CrMo4, the weight is 12.6kg. for the angle and radius, we can make it according to your bending request. Welcome to explore our quality press brake tooling and contact us for professional service!

Hemming upper punches of Bystronic-beyeler / bending tools 30°/R1 H = 175mm

The punch size is 175*22*515mm, 85degree, the material is 42CrMo4, the weight is 9.8kg. Welcome to explore our quality press brake tooling and contact us for professional service!

42CrMo material mold of straight tooling of beyeler R type 30 degree press brake punches

The punch size is 175*20*515mm, 30degree, the material is 42CrMo4, the weight is 12.8kg. for the angle and radius, we can make it according to your bending request. Welcome to explore our quality press brake tooling and contact us for professional service!

Bystronic-beyeler Single Vee die of V 8mm lower dies / bending tools

The die size is 75*20*515mm, 30degree, the material is 42CrMo4, the weight is 4kg. Welcome to explore our quality press brake tooling and contact us for professional service!

CNC Machining

Comely CNC's custom CNC milling services provide tailored solutions to enhance your productivity, efficiency, and quality control standards. We stand with excellence in delivering precision CNC milling services to a diverse range of industries. Our CNC milling services cater to the specific needs of our clients, who require precise part creation for manufacturing machines and end products. We utilize a range of machines, computer design options, and materials to provide high-quality milling services. By combining all factors in a unique way, we deliver exact parts that meet your requirements in a repeatable, quality-controlled process.

Single vee block V32mm Bystronic-beyeler press brake lower dies / bending tools - 85°/V32/R4 dies H = 55mm

The die size is 75*20*515mm, 85degree, the material is 42CrMo4, the weight is 10.8kg. Welcome to explore our quality press brake tooling and contact us for professional service!

Rapid Tooling

Also referred to as bridge tooling or prototype tooling, is a quick and cost-effective method of performing low-volume injection molding for diverse plastic part types. The creation of an aluminum or steel mold using the rapid tooling technique allows for its integration into the molding process to generate numerous copies of a component. Rapid tooling is employed to produce moldings that fulfill the demands of speedy prototyping within a condensed timeframe or to fill the interim gap prior to high-volume production.

Bystronic style single vee block V24mm / bending tools

The die size is 75*40*515mm, 30degree, the material is 42CrMo4, the weight is 7.8kg. Welcome to explore our quality press brake tooling and contact us for professional service!

Aluminum

Aluminum is a versatile and lightweight metal that is widely used in many industries. It is the third most abundant element on Earth's crust and has excellent properties that make it a popular choice for various applications. Aluminum has a high strength-to-weight ratio, making it strong and durable despite its light weight. It is also corrosion-resistant, which makes it ideal for use in harsh environments. Additionally, aluminum is an excellent conductor of electricity and heat, making it a common choice for electrical wiring and heat transfer applications. One of the most significant advantages of aluminum is its versatility. It can be easily formed into different shapes and sizes using a variety of manufacturing processes, including casting, forging, and extrusion. This flexibility allows it to be used in a wide range of products, including aircraft parts, automotive parts, consumer electronics, and building materials. Aluminum is also an environmentally friendly material. It is 100% recyclable, and the recycling process requires only 5% of the energy needed to produce new aluminum. This makes it an excellent choice for sustainable manufacturing practices. Material Tensile Strength (MPa) Yield Strength (MPa) Elastic Modulus (GPa) HARDNESS(HRB) ELONGATION(%) Advantages Applications Aluminum 6010-O 125 55 68.9 30 25 to 30 ● Corrosion resistance ● Machinability ● Formability Aircraft parts, bicycle frames, automotive parts, and electrical fittings. Aluminum 1060 63 21 69 19 27 ● Good corrosion resistance ● Easily machinable Decorative items, plumbing, electrical components, musical instruments Aluminum 2024-T4 324 186 73.1 120 20 ● High strength-to-weight ratio ● Excellent fatigue resistance ● Good machinability Aircraft structural components, bolts, and fasteners. Aluminum 5052-H32 210 193 70.3 60 12 ● Excellent corrosion resistance ● Formability ● Medium Strength Marine components, fuel tanks, and sheet metal work. Aluminum 5083 310 145 72.4 75 12 ● Excellent corrosion resistance ● Good weldability ● High strength Shipbuilding, pressure vessels, and cryogenic equipment. Aluminum 6061-T6 290 240 68.9 95 8 ● High strength ● Heat-treatable ● Corrosion Resistance ● Excellent machinability Structural components, bicycle frames, and automotive parts. Aluminum 6063-T5/T6 130 to 185 55 to 165 68.9 1.6-2.0 180-250 ● Good formability ● Excellent extrudability ● Corrosion Resistance ● Anodizing ● Heat-treatable Architectural framing, window frames, and piping. Aluminum 7075-T6 570 500 71.7 150 11 ● Excellent fatigue resistance ● Wear Resistance ● High strength Aerospace components, bicycle parts, and high-performance equipment. MIC-6 241 138 72.4 60 to 703 ● Good thermal conductivity ● Excellent flatness ● Good stability Tooling plates, jigs and fixtures, and machinery components.

Block vee dies of Bystronic style V50mm block vee press brake dies

The die size is 75*70*515mm, 60degree, the material is 42CrMo4, the weight is 12.6kg. Welcome to explore our quality press brake tooling and contact us for professional service!

Steel

Steel is a widely-used material in CNC machining due to its excellent mechanical properties, such as high strength and durability. The type of steel employed depends on the specific requirements for each component - strength, hardness, and corrosion resistance included. Stainless steel is a popular choice for CNC machining due to its corrosion resistance and ability to remain strong at high temperatures. Tool steel also makes an excellent CNC cutting material due to its high hardness and wear resistance. Other steel types used in CNC machining include carbon steel, which is cost-effective and easy to machine; and alloy steel which has improved mechanical properties due to the addition of elements like chromium, nickel, and molybdenum. In conclusion, when selecting steel type for CNC machining it's important to take into account your component's requirements as well as any properties needed for final product. Material Tensile Strength (MPa) Yield Strength (MPa) Elastic Modulus (GPa) Hardness (HB) Advantages Applications 1018 Steel 440-790 370 190 126-183 Good machinability, low cost Bolts, nuts, studs, gears 1020 Steel 420-690 350 190 121-170 Good weldability, low cost Shafts, axles, pins 1045 Steel 585-800 330 205 163-229 Good strength and wear resistance Gears, shafts, bolts 4130 Steel 670-980 435 205 197-235 High strength-to-weight ratio, good weldability Aircraft parts, bicycle frames 4140 Steel 655-1065 415 205 197-235 High strength, toughness, and wear resistance Gears, axles, shafts 4340 Steel 745-1130 470 205 201-269 High strength, toughness, and fatigue resistance Aircraft landing gear, crankshafts A2 Tool Steel 670-1280 360 190 217-235 High wear resistance, good toughness Punches, dies, cutting tools A36 Steel 400-550 250 200 70-80 Easy to machine, weld, and form. Affordable and widely available. Structural applications, including buildings, bridges, and machinery. D2 Tool Steel 1700-2200 1200-1400 190-210 60-64 High wear resistance and toughness. Holds an edge well. Cutting tools, knives, shear blades, and dies. S7 Tool Steel 1600-2000 1400-1700 190-210 50-60 High impact resistance and toughness. Tooling applications that require shock resistance, such as hammers, punches, chisels, and shear blades. 303 Stainless Steel 620 - 860 260 - 420 190 160 - 180 Good machinability and corrosion resistance Aerospace, automotive, food processing, and medical industries 304 Stainless Steel 515 - 1035 205 - 515 193 70 - 92 Corrosion resistance and high-temperature strength Chemical processing, food processing, and medical industries 316 Stainless Steel 515 - 1035 205 - 515 193 70 - 90 Superior corrosion resistance and high-temperature strength Chemical processing, food processing, and medical industries 416 Stainless Steel 550 - 860 275 - 485 200 262 - 302 Good machinability and wear resistance Aerospace, automotive, and manufacturing industries 15-5 PH 1100 - 1380 860 196 363 - 388 High strength, toughness, and corrosion resistance Aerospace, chemical processing, and medical industries 17-4 PH 1000 - 1200 800 190 302 - 363 High strength, toughness, and corrosion resistance Aerospace, chemical processing, and medical industries 440C 1960 - 2150 1320 200 58 - 64 High hardness and wear resistance Cutlery, bearings, and valve components

TRUMPF style press brake lower dies / bending tools - 80°/V24/R2.5 dies, H = 100 mm

The die size is 120*35*500mm, 80degree, the material is 42CrMo4, the weight is 14kg. for the angle, V opening and radius, we can make it according to your bending request. Welcome to explore our quality press brake tooling and contact us for professional service!

Sheet Metal

Sheet metal fabrication is a process by which components are created from sheet metal. This process can involve cutting, bending, and assembling the metal into a desired shape or form. Sheet metal prototyping is a subset of sheet metal fabrication and involves the rapid creation of a prototype or concept model using sheet metal parts and components.

TRUMPF style press brake lower dies / bending tools - 80°/V40/R5 dies, H = 100 mm

The die size is 120*55*500mm, 80degree, the material is 42CrMo4, the weight is 20.4kg. for the angle, V opening and radius, we can make it according to your bending request. Welcome to explore our quality press brake tooling and contact us for professional service!

Plastic Injection Molding

At Comely CNC, we pride ourselves on our ability to offer top-notch custom plastic injection molding services to businesses across a range of industries. Our team of experts has the knowledge and experience needed to ensure that each project we undertake is tailored to the specific needs of our clients. We've invested in state-of-the-art equipment and technology to ensure that our in-house capacity is always up to par, allowing us to offer rapid injection molding and on-demand production.

TRUMPF style press brake lower dies / bending tools - 80°/V100/R8 dies, H = 100 mm

The die size is 120*120*500mm, 80degree, the material is 42CrMo4, the weight is 44.7kg. for the angle, V opening and radius, we can make it according to your bending request. Welcome to explore our quality press brake tooling and contact us for professional service!

Finishing

Comely CNC provides a comprehensive range of finishing services to enhance the quality of your parts. Our services are tailored to meet your specific needs, whether it be appearance, mechanical, thermal, electrical, or other functional requirements. We offer a wide range of standard and customizable finishing services for all types of materials, including plastic and metal. Our services are designed to protect your parts' surface texture and improve their functionality and ergonomics, making them more suitable for everyday use. Choose from our various finishing options, including 3D-printed, die-casted, injection-molded, sheet metal, vacuum-casted, and aluminum-extruded parts, to give your products the perfect finishing touch.
